6310-2Z-NR SKF (6310ZZNR) Deep Grooved Ball Bearing with Snap Ring Groove 50x110x27 Metal Shields

6310-2Z-NR SKF (6310ZZNR) Deep Grooved Ball Bearing with Snap Ring Groove 50x110x27 Metal Shields, Supplied complete with Snap Ring

Deep Groove Ball Bearings are the most common bearing type found in a wide variety of applications. Versatile and robust they are available in a wide range of sizes and options including seals, shields and special clearance for high speed applications. The main types are:

• Open - Bearing without seals or shields, suitable for applications where lubricant will constantly flow through them i.e. gearboxes.

• Metal Shields - Bearings fitted with steel shields and lubricated for life.

• Rubber Seals - Bearings fitted with steel reinforced rubber contact seals which provide a better seal but add friction so are unsuitable for high speed applications, lubricated for life.
• C3 - Radial internal clearence greater than normal
• NR - Bearing with Snap Ring Groove and Snap Ring

6310-2Z-NR SKF dimension chart - all dimensions in mm unless indicated.

Inside Dia	Outside Dia	Width	Dynamic Load (kN)	Static Load (kN)	Limiting speed (r/min)
50	110	27	65	38	6700
